Schematic and Recordkeeping Documentation

Certified Medical Testing offers documentation and signage programs that address Multiple JCAHO Compliance Issues. The company’s AutoCad capability provides the ability to generate colored Piped Medical Gas system overlays on facility floor plan drawings. This contributes to compliance requirements as well as generate critical documents for maintenance and future construction guidance.

Many facilities have chosen to provide the required labels for ‘Zone Valve’ by extracting portions of the drawings to generate an immediate visual map. This map depicts each room and area that is controlled by that specific zone valve. The generation of these includes a survey which positively confirms the relationship between each outlet and zone valve. Thereby, eliminating the potential of an unknown source of supply.
